Name: China Customized insulating glass sealing tape Manufacturers, Suppliers, Factory - Cheap Price - Zhonghao
Brand: Zhonghao
SKU: 149864020

insulating glass sealing tape:

Standard size

Thinkness(MM)	Width(MM)	Length(Ｍ)
1mm	10～1000	15

Performances

ITEMS	Measurement value	Test Method
Thickness (mm)	0.5MM	-
Adhesive force（N/25mm）	Based on JIS 0237：2000 180°peel for stainless steel	50
Shear adhesion (N/cm2)	Adhesion test to shear direction	43
Retention force (min)	Hanging test piece with vertical position for adhesion area (10mmx20mm) and hooking a weight of 200g, measured the drop time.	110
Tensile elongation (%)	Based on JIS 0237：2000	9

Remark: as No.9805 is double coated tape, the adhesion force of both sides is the same.Adhesion property to representative substrates

NO.	Substrates		Test Method (N/25mm)
1	Stainless board		48
2	Veneer board		36
3	Nonflammable board		35
4	Calcium silicate board		33
5	Polyvinyl chloride coated steel panel	Surface	48
		Back	54
6	Color coated steel panel	Surface	54
		Back	57
Remark	Temperature23±2℃

insulating glass sealing tape

Features:

●Good for durability, adhesion to coarse surfaces, water-proof, water resistant, anti-alkaline solution
●Low contamination, low sagging for adhesive layer even in the summer time weather
●Good adhesion for complicated parts because this tape is flexible even in the winter time

Uses:

●Fixation for artificial turf
●Temporary fixation for panels like non-inflammable board, artificial turf, heat insulator, plywood
●Airtight seal for panel, joint part of inside walls, penetration hall
●Water proof seal for joint part of the building basis
